Power Integrations LNK306DG-TL LNK306DG
Configuration
1 options
Configuration
Date code within 2 years
Available for RFQ
Technical data
Product details
19
specifications
Core information
- Product name
- Power Integrations LNK306DG-TL
- Type
- POWER INTEGRATIONS
- Minimum package
- 2500 圆盘
Technical parameters
- Electronic Component
- Electronic Component
- Electronic Component
- POWER INTEGRATIONS
- Electronic Component
- LNK306DG-TL
- Electronic Component
- 1
- Package
- SO-7
- Electronic Component
- AC-DC Controllers and Regulators
- Electronic Component
- 0.22g
- Electronic Component
- 1
- Features
- EMI Optimization;; (OTP); (SCP);; (OCP)
- Electronic Component
- BM0000514896
- Electronic Component
- CCM；DCM
- Operating Temperature
- 40℃~+150℃
- Switching Frequency
- 66kHz
- Isolation
- Non-isolated
- Output Current
- 360mA
- Transistor Voltage Rating
- 700V
For datasheets, package documents, compatible-part guidance, or other technical resources, contact WMSIC customer service. Availability is confirmed case by case.
LNK306DG-TL 产品概述
基本信息
LNK306DG-TL是由Power Integrations（帕沃英蒂格盛）设计的一款高性能离线转换器，采用SO-8C表面贴装封装。该元件适用于多种应用，包括但不限于低功耗开关电源、LED驱动器和其他需要高效能的电源管理任务。这款器件的关键特性包括内部开关设计、卓越的敬破性能和多种拓扑结构的支持，使其在各类电子应用中具备广泛的适应性。
电气特性
LNK306DG-TL的击穿电压高达700V，这为其提供了极好的电气耐受性能，能够适应高压环境中的工作条件。其开关频率为66kHz，这一频率的选择在保证转换效率的同时，有助于减小输出滤波器的体积。此外，产品支持降压、降压升压和反激三种拓扑结构，使得该转换器能够灵活应对不同的电源设计需求。
工作温度范围
本产品的工作温度范围为-40°C至150°C（TJ），在严苛环境下也能确保稳定的性能表现。这一广泛的温度适应性使得LNK306DG-TL能够广泛应用于汽车、工业、消费类电子等多个领域，能够满足各种环境下的电源需求。
故障保护机制
LNK306DG-TL内置多种故障保护功能，包括限流、开环、超温和短路保护，确保了在各种异常情况下的安全性与稳定性。限流保护机制能够有效防止输出端短路时的过流情况，而开环保护则能够监测到系统故障，避免设备进一步损坏。此外，超温保护可以在温度过高时自动降低输出功率，避免器件因过热而失效。
输出隔离与占空比
此款离线转换器具备非隔离输出设计，能够简化电路设计并降低成本。LNK306DG-TL具有最高69%的占空比，确保在稳定输出功率的同时，能够有效达到较高的能量转换效率。这一优势不仅提高了电源的工作效率，也有助于降低整体能耗，符合现代电子产品对节能的广泛要求。
应用场景
LNK306DG-TL凭借其优良的性能特征，适用于多种应用领域。其中包括：
- LED驱动：高效的能量转换和稳定的输出特性使其成为LED照明应用的理想选择，能够支持多种LED驱动器设计。
- 家电电源：由于其工作温度范围和高电压击穿能力，适合用于各种家电产品的电源管理。
- 工业控制系统：在工业自动化和控制设备中，LNK306DG-TL的多种保护机制保障系统的可靠性，适合使用于PLC、传感器和执行器等设备中。
- 网络设备：作为网络设备供电解决方案的一部分，能够确保数据传输的稳定性与安全性。
总结
LNK306DG-TL是设计精良的离线转换器，凭借其高击穿电压、卓越的转化效率和多种保护机制，使其在电源管理和控制领域的应用越来越广泛。无论面临什么样的工作环境或电源要求，LNK306DG-TL都能提供可靠的解决方案，是现代电子设计中不可或缺的重要组件。
