SGMICRO SGM721XN5/TR SGM721XN5
Configuration
1 options
Configuration
Date code within 2 years
Available for RFQ
Technical data
Product details
19
specifications
Core information
- Product name
- SGMICRO SGM721XN5 / TR
- Type
- SGMICRO
- Minimum package
- 3000
Technical parameters
- Electronic Component
- SGMICRO
- Electronic Component
- SGM721XN5/TR
- Electronic Component
- 1
- Package
- SOT-23-5
- Electronic Component
- Operational Amplifier
- Electronic Component
- 0.17g
- Electronic Component
- 1
- Electronic Component
- Output
- Electronic Component
- BM69416075
- Operating Temperature
- 40℃~+125℃
- Amplifier
- 1
- Output Current
- 67mA
- (SR)
- 8.5V/us
- Power Supply Voltage
- 2.1V~5.5V
- Static Current(Iq)
- 1.2mA
- Electronic Component
- 3000
For datasheets, package documents, compatible-part guidance, or other technical resources, contact WMSIC customer service. Availability is confirmed case by case.
产品概述：SGM721XN5/TR 运算放大器
一、基本信息
SGM721XN5/TR 是 SGMICRO（圣邦微）推出的一款高性能运算放大器，具有 11MHz 的带宽并支持 Rail-to-Rail 输入和输出，采用小型 SOT-23-5 封装。由于其高带宽和出色的线性性能，SGM721XN5/TR 被广泛应用于各种模拟信号处理和微控制器接口电路。
二、技术特点
高带宽： SGM721XN5/TR 的增益带宽产品为 11MHz，允许设计人员在高频应用中保持出色的放大性能。该特性使得其在快速响应和动态信号处理方面表现优越。
Rail-to-Rail I/O： 该放大器支持 Rail-to-Rail 输入和输出，使得其可以在电源范围内处理几乎完整的输入和输出信号。这一特性极大地提高了设计的灵活性，尤其是在低电压应用中，能够充分利用电源的工作范围。
低功耗设计： SGM721XN5/TR 的静态电流仅为 100μA，适合于便携式和低功耗电子设备。其出色的功耗特性使得它非常适合于电池供电的系统，能够 延长设备的使用寿命。
小型封装： SOT-23-5 封装设计使得 SGM721XN5/TR 易于集成到各种紧凑设计中，尤其适合于空间受限的应用场合，例如移动设备、传感器前端电路等。
宽电源电压范围： 该产品支持广泛的供电电压范围，通常为 +2.7V 至 +5.5V，适合多种电源配置，增加了其在不同应用中的适应性。
三、应用领域
SGM721XN5/TR 运算放大器因其出色的性能指标被广泛应用于以下领域：
信号处理： 适用于音频、视频、传感器信号放大和解调等信号处理应用，能够有效保持信号的完整性和线性度。
数据采集系统： 在数据采集系统中，该放大器能够快速处理输入信号并为模数转换器（ADC）提供准确的电压信号，提升系统的精度和可靠性。
传感器接口： SGM721XN5/TR 能够与各种类型的传感器（如温度、压力、光电等传感器）相结合，提供高精度的信号放大和调理。
便携式设备： 由于其低功耗特性，该运算放大器特别适合应用于便携式医疗设备、可穿戴设备等对电池续航有较高要求的场景。
家用电器： 在智能家居和家用电器中，SGM721XN5/TR 可用于多种控制和信号处理任务，如温控器、智能门锁等。
四、总结
SGM721XN5/TR 运算放大器是一款具有高带宽、低功耗以及 Rail-to-Rail I/O 特性的高性能放大器，适合多种应用场景。它的小型封装设计使得其在现代电子产品中得到了广泛应用。无论是在专业的工业级信号处理，还是在日常的消费电子产品中，SGM721XN5/TR 始终能够提供稳定可靠的性能，满足现代电路设计日益增长的需求。设计人员可以通过使用该运算放大器来提高系统的整体性能，确保设计的成功和产品的竞争力。
