PANJIT 1SMA4744_R1_00001
Configuration
1 options
Configuration
24+
Available for RFQ
Technical data
Product details
19
specifications
Core information
- Product name
- PANJIT 1SMA4744_R1_00001
- Type
- PANJIT
- Minimum package
- 1800 圆盘
Technical parameters
- Electronic Component
- Electronic Component
- Electronic Component
- PANJIT
- Electronic Component
- 1SMA4744_R1_00001
- Electronic Component
- 1
- Package
- SMA(DO-214AC)
- Electronic Component
- Zener Diode
- Electronic Component
- 0.108g
- Electronic Component
- 1
- (Zzk)
- 700Ω
- (Zzt)
- 14Ω
- Electronic Component
- BM69416312
- Diode
- 1
- Current(Ir)
- [email protected]
- Power Dissipation(Pd)
- 1W
- Electronic Component
- 14.25V~15.75V
- Electronic Component
- 50℃~+150℃
For datasheets, package documents, compatible-part guidance, or other technical resources, contact WMSIC customer service. Availability is confirmed case by case.
产品概述：SMA4744_R1_00001 稳压二极管
一、产品简介
SMA4744_R1_00001是一款高性能的稳压二极管，专为电源管理及电压调节设计。其稳压功能在15V的电压范围内表现优异，适合各种电子设备的应用，包括但不限于电源电路、过压保护、信号调节等场合。这款产品由知名电子元器件制造商Panjit（强茂）生产，采用SMA(DO-214AC)封装，具有良好的散热性能以及可靠适应性。
二、技术规格
- 类型: 稳压二极管
- 额定电压: 15V
- 稳压范围: 14.25V~15.75V
- 漏电流: 100nA @ 11.4V
- 封装形式: SMA(DO-214AC)
三、应用领域
SMA4744_R1_00001稳压二极管广泛应用于以下领域：
- 电源保护: 可用于电源电路的过压保护，以保证其他元器件的安全使用。
- 信号调节: 可以有效稳压和调节信号电压，确保信号传输的稳定性。
- LED驱动: 适用于LED驱动电路中的电压控制，以防止因电压波动造成LED亮度不均或损坏。
- 消费类电子产品: 如电视、音响和其他家庭电器，能够为不同的电路板提供稳定的工作电压。
四、工作原理
稳压二极管工作在反向击穿区，能够在保持一定电压的同时，允许电流通过。当外部电路施加超过其稳压阈值的电压时，稳压二极管就会“导通”并限制输出电压在其额定值附近，从而实现电压的稳定。其高压抑制能力使其在电压大幅波动的情况下仍能保护电路。
五、设计优点
- 高稳定性: 由于其泄漏电流在11.4V时仅为100nA，SMA4744确保了在大多数条件下的高稳定性和低功耗特性。
- 热性能优越: SMA封装形式有助于增强散热性能，提高器件的工作可靠性和寿命。
- 尺寸小巧: SMA封装相对较小，适合空间受限的设计要求，可以轻松集成到各种电路板中。
- 适应性强: 本产品设计兼容多种电气特性，可以广泛应用于不同类型的电路和系统中。
六、安装建议
安装SMA4744_R1_00001稳压二极管时，确保遵循适当的电路设计规范，特别是在选择合适的引脚布局和焊接技术时。此外，应注意二极管的极性，以确保其正常工作并发挥最佳性能。建议在电路中预留必要的保护措施，以应对突发的电压变化。
七、结论
总之，SMA4744_R1_00001稳压二极管是电源管理和电压调节应用中的优选元件，凭借其优越的技术性能和可靠性，可以为各类电子产品提供稳定的电压支持。无论是用于消费类电子还是工业设备，其优质的电气特性都将大幅提升整体系统的稳定性和安全性。选择SMA4744_R1_00001，将为您的产品加分！
